    HF-SY320S LED — shadowless ceiling LED operating lamp for standard surgical procedures

    HF-SY320S LED is a shadowless ceiling LED operating lamp from the SY320 series — mid-range solution for standard surgical procedures in general operating rooms. Compact design, good price-performance, reliable operation.

    SY320 series — configurations

    • HF-SY320 (LED) — mobile on stand
    • HF-SY320S (LED) — ceiling mount (this product)
    • HF-SY320C (LED) — ceiling with compact design
    • HF-SY320W (LED) — wall mount
    • HF-SY320E (LED) — mobile with backup battery
    • HF-SY320/SY320C (LED) — dual (mobile + ceiling)

    Key advantages

    • Shadowless design — uniform field without shadows via multi-LED configuration
    • Ceiling mount — saves floor space
    • LED technology — no heat radiation
    • CRI ≥90 — accurate color rendering
    • Adjustable brightness
    • Flexible spring arm with full 360° rotation
    • Sterilizable handle
    • Balanced price-performance — optimal for medium clinics
    • Compact lamp design
    • Quick installation and calibration

    Applications

    • General surgical operations
    • Gynecology and obstetrics
    • Urology
    • Dental surgery
    • Minor and medium-major surgery
    • Emergency operations

    Optics

    TypeLED shadowless
    Peak illumination (1m)~ 80,000 lux
    CRI (Ra)≥ 90
    Color temperature~ 4,500 K
    Field size~ 200-280 mm
    Brightness adjustmentYes

    LED

    CountMulti-LED configuration
    Lifespan> 50,000 hours

    Construction

    MountingCeiling spring arm
    Rotation360°
    Sterilizable handleYes

    Power

    AC100-240 V, 50/60 Hz

    Certifications

    StandardsCE, ISO 13485, IEC 60601-1

    Documents to download

    HF-SY320S LED — Brochure (ENG) (PDF)

    Frequently asked questions about HF-SY320S LED

    What is the difference between SY320S and SY320C?

    Both are ceiling-mounted. SY320S is the standard version. SY320C is a more compact version. Choice depends on operating room size and aesthetic preference.

    SY320S vs L60 — which to choose?

    SY320S is mid-range (~80,000 lux), optimal for general and standard surgical procedures. L60 is premium (~160,000 lux), for specialty/complex procedures and large operating rooms. Price-performance — SY320 is more affordable.

    What is "shadowless"?

    Shadowless design means the lamp uses multiple LEDs distributed across the surface, so when surgeon or assistant partially covers the lamp with hand/head, light from other LEDs compensates the shadow. Result: uniform field without dark spots.

    Is there an Endo Mode?

    Standard SY320S does not include dedicated Endo Mode. For laparoscopy and endoscopy we recommend L60/L60C, L84 or 700/500 LED series. Alternatively — manually reduce SY320S brightness.

    What installation does it require?

    Ceiling with load capacity ≥40 kg, electrical supply directly above desired position and flange (mounting tube) appropriate for ceiling height. Standard flanges 250-500 mm.
